Description
|
Type
|
|
|
RF and Wireless -> RF Transceiver Modules and Modems |
Category
|
|
|
SIMCom Wireless Solutions Limited |
Mfr
|
|
|
GSM/GPRS |
RF Family/Standard
|
|
|
GSM Phase 2/2+, GPRS |
Protocol
|
|
|
GMSK, 8PSK, QPSK |
Modulation
|
|
|
850/900/1800/1900 MHz (Quad-Band) |
Frequency
|
|
|
85.6 kbps max (downlink/uplink) |
Data Rate
|
|
|
2 W @ 850/900 MHz, 1 W @ 1800/1900 MHz |
Power
|
|
|
- |
Sensitivity
|
|
|
UART, I2C, USB |
Serial Interfaces
|
|
|
- |
Antenna Type
|
|
|
32MB |
Memory Size
|
|
|
3.4V ~ 4.4V |
Voltage - Supply
|
|
|
20-25mA (Idle), 50-80mA (Receiving Data - GPRS), 20-40mA (GSM Signal Reception) |
Current - Receiving
|
|
|
150-300mA (Sending Data - GPRS), 500-1000mA (GSM Voice Call) |
Current - Transmitting
|
|
|
Surface Mount |
Mounting Type
|
|
|
-40°C ~ 85°C |
Operating Temperature
|
|
|
|
|
